Manitou
100 VJR
Electric vertical boom lift (mobile elevating work platform) from Manitou with 9.85 metres working height. Narrow and highly manoeuvrable, built for indoor work in tight spaces and warehouses.
- Working height
- 9,85 m
- Lifting capasity
- 200 kg
- Lifting height
- 3,1 m
- Energy type
- EL
Description
The 100 VJR is an electric mobile elevating work platform from Manitou, of the vertical mast lift type with a jib.
It is the larger of the two VJR models in Manitou's range of mobile elevating work platforms. V stands for vertical mast, J for jib and R for rotation. The number 100 refers to the working height of approximately 10 metres. Where the 80 VJR reaches 7.65 metres, the 100 VJR extends to 9.85 metres, and the jib provides an outreach of 3.10 metres to the side.
The machine is just as narrow as its sibling at 99 cm wide and passes through most industrial doors and tight aisles. The non-marking tyres protect floor coverings, the turret rotates 350 degrees, and the battery lasts a full working day.
Typical applications are maintenance of technical installations, lighting and ventilation systems, work in shelving systems and high-bay warehouses, and indoor facade and ceiling finishing work in large buildings where the jib provides the necessary flexibility to reach around edges and over obstacles.
If you need a smaller machine, the 80 VJR is available with 7.65 metres of working height. If you need to reach further out and around obstacles, an articulating boom lift such as the 150 AETJ-C is an alternative.
Operating a mobile elevating work platform of this type requires a valid certificate, which can be obtained through a machine operator course with us.
